Here on the History Page, you can read about the history of these unique locomotives and how they arrived into Santa Fe service, as well as read on the status notes of the actual engines in Santa Fe's service.


SDF40-2 - Their History

      Santa Fe's SDF40-2 were originally built for Amtrak, and their original designation was SDP40F. They were first brand new locomotive units bought by the fledgling passenger service.

      Amtrak's decision to buy modern power came from the notion that the locomotives could be converted into freight engines should Amtrak fail. Amtrak gave the nod to EMD, although GE had produced the U30CG. The specifications given to EMD were to produce a locomotive similar in outward appearance to the FP45, however would have the interior components of the SD40-2. Amtrak also opted for the more economical 16-cylinder engine instead of the 20-cylinder engine, thus adding better fuel economy and reliability to the new class of locomotives.

      The new SDP40F locomotives were delivered in 1973 and 1974 to Amtrak. The company pressed them into cross-country service almost immediately after delivery. Amtrak looked favorably on the new locomotives, and was planning on retiring its hand-me-down and older engines now that new power was finally at hand.

      Things continued to look upward for Amtrak and the new SDP40Fs until 1976. Almost from the start, train crews commented to management about the "yawing" of the trucks which were causing rough riding and minor derailments. Later on in that year, both the Burlington Northern and the Louisville and Nashville suffered serious derailments on 2-degree curves involving the SDP40F. The Burlington Northern decreed that no SDP40F would run on its rails after the incident. The company relented only after a Federal Rail Administration ruling subjecting the SDP40F to speeds no greater than 40 MPH on 2-degree or greater curves.

      Most of the blame for the series of accidents was pointed to the SDP40F's unique hollow-bolster HTC truck. Many tests were conducted to try to prove if the truck was indeed at fault, however no test was ever conclusive.

      Amtrak's image was beginning to suffer immensely because of the major problems with the SDP40F, however Amtrak was at the same time beginning to receive a four-axle F40PH locomotive, and the decision was made to replace the SDP40F with the F40PH.

      After only eight years of service on Amtrak, most of the SDP40F locomotives were traded back to EMD to have their components installed into new F40PH locomotives, and the remaining units were reduced to meaningless assignments on Amtrak maintenance of way trains.       In 1984, things began to brighten for the SDP40F. Amtrak was looking for small power for terminal jobs, and the company turned to the Atchison, Topeka and Santa Fe Railway for help. Santa Fe had an excess of its homemade CF7s and SSB1200 switch locomotives, which it offered to Amtrak. In turn, Amtrak traded 18 SDP40Fs for 25 CF7s and 8 SSB1200 locomotives.

      Of the 18 units received by Santa Fe, two were of the Phase 1 variety, and the remaining 16 were of the Phase 2 designation. The Phase 1 spotting features had a "pointed" nose and a large, boxy exhaust silencer on top of the exhaust stack. The Phase 2 features included a flattened nose, and a low profile exhaust silencer.

      The new SDP40F locomotives briefly pulled freight for their new owners in their former Amtrak paint schemes. Then in 1985, Santa Fe sent all the locomotives to its famed San Bernardino, CA shops for rebuilding. The engines emerged in the new blue and yellow paint scheme as well as a new model designation: SDF40-2. Santa Fe placed them in the roster from #5250-#5267.

      Santa Fe also changed the external appearance of the new locomotives by blanking out or plating over the doors and the vents at the back of the units which once housed the passenger equipment, and concrete poured in its place. Also the pointed nose on the Phase I units was flattened out, and a new nose door and front handrails were added. However during operation time, these improvements were deemed unsafe for train crews, and the locomotives were again modified. This time, new sloping steps, similar to standard EMD locomotives, were added, and a "notch" added in each side of the nose for safer and more convenient locomotive access by train crews.

      In 1994, maintenance of these locomotives was turned over to Morrison Knudsen, and small "MKM" letters were added under the locomotives' engine numbers. Currently most of the locomotives have been renumbered into the Burlington Northern Santa Fe roster from #6960 to #6977. The only unit to be retired was ATSF #5263, as she was wrecked 11/13/98 at Barstow CA and retired 4/30/99.

[Top of Page]


SDF40-2 Locomotive Notes

Last ATSF Number Original ATSF Number Disposition/Status Notes
5250 643 blt as Amtrak SDP40F 643; acquired 9/84, Amtrak markings removed; reblt 1/85 to SDF40-2 5250; maintenance transferred 4/94 to MK
5251 511 blt as Amtrak SDP40F 511; acquired 9/84, Amtrak markings removed; reblt 2/85 to SDF40-2 5251; maintenance transferred 4/94 to MK
5252 615 blt as Amtrak SDP40F 615; acquired 9/84, Amtrak markings removed; reblt 2/85 to SDF40-2 5252; maintenance transferred 4/94 to MK
5253 630 blt as Amtrak SDP40F 630; acquired 9/84, Amtrak markings removed; reblt 2/85 to SDF40-2 5253; maintenance transferred 4/94 to MK; renum 10/98 to BNSF 6963
5254 635 blt as Amtrak SDP40F 635; acquired 9/84, Amtrak markings removed; reblt 2/85 to SDF40-2 5254; maintenance transferred 4/94 to MK; renum 3/98 to BNSF 6964
5255 526 blt as Amtrak SDP40F 526; acquired 9/84, Amtrak markings removed; reblt 2/85 to SDF40-2 5255; maintenance transferred 4/94 to MK; renum 2/98 to BNSF 6965
5256 640 blt as Amtrak SDP40F 640; acquired 9/84, Amtrak markings removed; reblt 3/85 to SDF40-2 5256; maintenance transferred 4/94 to MK; renum 2/98 to BNSF 6966
5257 622 blt as Amtrak SDP40F 622; acquired 9/84, Amtrak markings removed; reblt 3/85 to SDF40-2 5257; maintenance transferred 4/94 to MK
5258 628 blt as Amtrak SDP40F 628; acquired 9/84, Amtrak markings removed; reblt 3/85 to SDF40-2 5258; maintenance transferred 4/94 to MK; renum 3/98 to BNSF 6958
5259 633 blt as Amtrak SDP40F 633; acquired 9/84, Amtrak markings removed; reblt 3/85 to SDF40-2 5259; maintenance transferred 4/94 to MK; renum 5/98 to BNSF 6969
5260 638 blt as Amtrak SDP40F 638; acquired 9/84, Amtrak markings removed; reblt 3/85 to SDF40-2 5260; maintenance transferred 4/94 to MK; renum 9/98 to BNSF 6970
5261 634 blt as Amtrak SDP40F 634; acquired 9/84, Amtrak markings removed; reblt 4/85 to SDF40-2 5261; maintenance transferred 4/94 to MK; renum 6/98 to BNSF 6971
5262 629 blt as Amtrak SDP40F 629; acquired 9/84, Amtrak markings removed; reblt 4/85 to SDF40-2 5262; maintenance transferred 4/94 to MK; renum 3/98 to BNSF 6972
5263 639 blt as Amtrak SDP40F 639; acquired 9/84, Amtrak markings removed; reblt 4/85 to SDF40-2 5263; maintenance transferred 4/94 to MK
5264 632 blt as Amtrak SDP40F 632; acquired 9/84, Amtrak markings removed; reblt 4/85 to SDF40-2 5264; maintenance transferred 4/94 to MK; renum 3/98 to BNSF 6974
5265 649 blt as Amtrak SDP40F 649; acquired 9/84, Amtrak markings removed; reblt 4/85 to SDF40-2 5265; maintenance transferred 4/94 to MK; renum 2/98 to BNSF 6975
5266 644 blt as Amtrak SDP40F 644; acquired 9/84, Amtrak markings removed; reblt 5/85 to SDF40-2 5266; maintenance transferred 4/94 to MK; renum 4/98 to BNSF 6976
5267 645 blt as Amtrak SDP40F 645; acquired 9/84, Amtrak markings removed; reblt 5/85 to SDF40-2 5267; maintenance transferred 4/94 to MK; renum 5/98 to BNSF 6977
